5-520315-8
Manufacturer:
TE Connectivity
Mfr.Part #:
5-520315-8
Datasheet:
Description:
FFC / FPC Through Hole Number of Positions:8 1 A 250 V
| Parameter | Value |
|---|---|
| Length | 25.22 mm |
| Termination | Solder |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -55 °C |
| Height | 6.93 mm |
| Packaging | Bulk |
| Voltage Rating | 250 V |
| Depth | 4.83 mm |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| Lead Pitch | 2.54 mm |
| REACH SVHC | Unknown |
| Contact Plating | Tin |
| Lead Length | 3.56 mm |
| Contact Material(Contact Finish) | Bronze |
| Pitch | 2.54 mm |
| Current Rating | 1 A |
| Flammability Rating | UL94V-0 |
| Orientation | Vertical |
| Lifecycle Status | Production (Last Updated: 1 week ago) |
| Color | Black |
| Gender | Female |
| Number of Contacts | 8 |
| ELV | Compliant |
| Connector Type | Connector, Receptacle, Socket |
| Number of Positions | 8 |
| Number of Rows | 1 |
| Housing Material | Thermoplastic |
| Connector System | Wire-to-Board |
| Contact Style | Socket |
| Housing Color | Black |
| PCB Mounting Orientation | Vertical |
| PCB Thickness | 1.57 mm |
| Tail Length | 3.56 mm |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 1 week ago) |
| Sealable | No |
| Mating Alignment | With |
| Mating Connector Lock | Without |
Stock: 1640
Distributors
pcbx
pcbxUnit Price$0.80021
Ext.Price$0.80021
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.80021 | $0.80021 |
| 10 | $0.68907 | $6.89070 |
| 25 | $0.61042 | $15.26050 |
| 50 | $0.54540 | $27.27000 |
| 100 | $0.48731 | $48.73100 |
| 300 | $0.41550 | $124.65000 |
